| Product Name: | Chips packing machine | Application: | Food, chemical |
|---|---|---|---|
| Driven type: | Electric and penumatic | Control way: | PLC |
| Made of: | SUS 304 | Feature: | Volumetric cups to measure |
| Standard: | CE/ROHS/FCC/SGS | Operating language: | English and Chinese |
| Bag shape: | Stick | Capacity: | 30-45 bags per minute |
| แสงสูง: | food product packaging machine,automatic food packing machine |
||
Plastic Stick Bag Potato Chips Food Packing Machine
I.: How to choose right machine?
Please tell us following points to choose a right model packing machine:
1. What product will you pack?
2. How many gram and volume in each bag?
3. What bag shape you want to get?
4. What is bag width and bag length?
5. What bag material do you want to use?
II.: Specifications:
|
Packaging type |
Plastic stick shape bag |
|
Driven Type |
Electric |
|
Measurement accuracy |
<= +- 1% |
|
Lanes quantity |
Only one |
|
Machine made of |
SUS 304 (for parts contacted material) |
|
Packaging material |
Laminated roll film |
|
Electric voltage |
380V |
|
Measurement device |
Multi-head combination weighter |
|
Date coding |
Ribbon printer(for chosen) |
III.: Description:
1. sealing type: back sealing packing method.
2. operation: packing running data and adjustment are directly displayed on the display. the user can directly
operate it on the displayer.
3. function: making bag, metering, filling, sealing, cutting, counting and printing batch number.
4. body material: 304 stainless steel
5. filling type: multi-head combination weighter.
6. This machine can finish measuring, pulling, feeding, forming, cutting automatically.
7. Chinese-English operating screen display, easy operation and maintenance.
8. Mitsubishi PLC control system insure steady working conditions, and available to adjust any parameter without stopping the machine.
9. Adopt step motor to pull film, more accurate.
10. Independent temperature control system, precision±1 degree.
11. Independent control of horizontal / longitudinal temperature, to ensure a good fit of various kinds of complex film.
12. Automatic alarm protects system, to save the waste into minimum limited.
13. for the weighter, high-accuracy, high speed; choose the best fit though the computer.
14. for the weigther, high-accuracy digital weighed sensor to ensure instantaneous counting.
15. for the weighter, waterproof and dustproof function to keep clean.
16. for the weighter, automatic slight adjustment of hopper door to avoid crash and seize.
17. for the weighter, automatic counting system to record total production, percent of pass, single bag error.
IV.: Applications:
|
Applicable product |
chips, kinds of granulated food and so on. |
|
Applicable field |
Food, daily consumption, medicine, chemicals, hardware… |
V.: Questions asking:
What’s material of machine frame?
Carbon steel and stainless steel are available.
What’s the material for contacted parts of machine?
Stainless steel
For the control panel, how many languages are available?
Usually, English and Chinese are available.
What kind of packing film can be used?
Complex film roll, such as OPP/CPP,CPP/PE,MST/PE/PET/PE.
What is your advantage?
1. Stable and reliable performance of machine, competitive price.
2. To reply your enquiry promptly
3. Low price of spare parts if you need more.
4. In case some malfunction, we promptly offer on-line service, such as E-mail, skype, wechat,viber, whatsapp to supply videos, pictures.
5. Professional technicians are available.
